NISSAN R35 GT-R
GT800 Racing Spec
Battle for time attack.
600ps was top power output for the sport cars before. But for R35 GT-R it's only result of light tuning output. It has much more potentioal for higher power. If you want race in a circuit, you need more need more power to win. And the racing specification GT800 can produce 800ps to battle on the circuit with the R35 GT-R's symmetric twin turbo and engine that support it.
GT1000 Racing Spec
To be No. 1 in all places.
It's very important to be No. 1 with the R35 GT-r because it's No. 1 sport car in Japan. But that doesn't mean to make the top speed machine. It's not difficult to make the top speed with this monstrous machine. But even if you have the fastest speed machine, and can't control it, it means nothing. You ca't win the battle in a race. You need to be No. 1 in all system like torque, suspension, cooling, clutch, electronics and etc. To become No. 1 with R35 GT-R HKS GT1000 is the perfect tuning menu.
GT1000+ Racing Spec
For higher performance.
It's very important to be No. 1 with the R35 GT-R because it's No. 1 sport car in Japan. But, it is impossible to remain No. ; it is always overtaken. Number one spec. for R35 GT-r is caught up with and overtaken by others soon. HKS has challenged time attacks several times with the monstrous machine named after GT1000+ Racing Spec. GT1000+ Racing Spec has been completed with newly designed turbines having larger air capacity than GT1000 Racing Spec.
HKS 2014 WTAC - Chapter 1 Japan
Parts List
| Code No. | Product | Price | Remarks |
| FULL TURBINE KIT | |||
| 11003-AN013 | R35 GT-R GT1000 FULL TURBINE KIT | $10,000.00 | Turbine Size: GTII 7867 & GTII 7867R, Boost Pressure: 88.3kPa (0.9kgf/cm2), Off-road use only, Box#2: 750x450x300 21kg |
| 11003-AN016 | R35 GTIII 800 FULL TURBINE KIT | $8,500.00 | |
| 11003-AN014 | R35 GT-R GT900 FULL TURBINE KIT | $11,300.00 | Box 1 - Weight 14kg, Length 685mm, Width 270mm, Height 270mm Box 2 - Weight 29.5kg, Length 1161mm, Width 460mm, Height 290mm |
| 11003-AN015 | R35 GT-R GT1000+ FULL TURBINE KIT | $12,300.00 | Box 1 - Weight 14kg, Length 685mm, Width 270mm, Height 270mm Box 2 - Weight 34.5kg, Length 1160mm, Width 460mm, Height 290mm |
| 11003-AN011 | R35GT-R GT800 FULL TURBINE KIT | $8,500.00 | Turbine Size: GT II 7460 & GT II 7460R, Boost Pressure: 88.3kPa (0.9kgf/cm2), Box#2: 750x450x300 18.9Kg |
| INTERCOOLER KIT | |||
| 13001-AN013 | I/C R35 VR38DETT GT-R | $4,000.00 | R type INTERCOOLER, Core Size/Location: 400X260X65/2/Front mount, Can’t install carbon air guide for 2011 spec. Can install to a left‐hand drive car. Not checked for SPEC V, Box#2: 760x470x320 3.5kg |
| 13001-AN014 | I/C R35 VR38DETT GT-R (DUCT LESS) | $3,200.00 | R type INTERCOOLER, Core Size/Location: 400X260X65/2/Front mount, Can install to a carbon air guide-less and a left-hand drive car. Not checked for SPEC V. |
| 13001-AN015 | I/C R35 VR38DETT (GT1000 SPEC) | $4,000.00 | R type INTERCOOLER, Core Size/Location: 390x270x100/2pcs /Front mount, Type: GT1000SPEC, Need separate piping kit (13002-AN003) Can install to a left‐hand drive car. Not checked for SPEC V. |
| PIPING KIT | |||
| 13002-AN003 | I/C PIPING KIT R35GT-R | $1,000.00 | HKS Super SQV4 Kit (P/N 71008-AN027) is required for installation. Type: IC, In pipe (Number of pipes): 2, Out pipe (Number of pipes): 4, Buff finish |
| 13002-AN004 | I/C FULL PIPING KIT R35 GT-R | $1,550.00 | This is a combination of 13002-AN003 and 71008-AN027. |
| HIGH FLOW SURGE TANK | |||
| 13008-AN001 | HI-FLOW SURGE TANK FULL KIT R35 GT-R | $3,700.00 | HIGH-FLOW SURGE TANK FULL KIT, Surge Tank + Twin Injector Pro kit |
| 13008-AN002 | HI-FLOW SURGE TANK R35 GT-R | $2,700.00 | HIGH-FLOW SURGE TANK ONLY |
| 14007-AN004 | TWIN INJECTOR PRO KIT R35 GT-R | $1,600.00 | TWIN INJECTOR PRO KIT for 13008-AN002 |
| GT TURBINE UNIVERSAL | |||
| 14001-AK017 | GTII7460 SYMMETRY TWINTURBO | $5,000.00 | Product: GTII 7460 SYMMETRY SERIES, GT800SPEC, Turbocharger main body x2 |
| 14001-AK019 | GTII7867 SYMMETRY TWINTURBO | $6,500.00 | Product: GTII 7867 SYMMETRY SERIES, GT1000SPEC, Turbocharger main body x2 |
| 14001-AK024 | GTII7467 SYMMETRY TWINTURBO | $6,500.00 | Product: GTII 7467 SYMMETRY SERIES, GT900SPEC, Turbocharger main body x2 |
| 14001-AK027 | GTII8267 SYMMETRY TWINTURBO | $6,800.00 | Product: GTII 8267 SYMMETRY SERIES, GT1000+SPEC, Turbocharger main body x2 |
| FUEL PUMP UPGRADE | |||
| 14007-AN003 | FUEL PUMP UPGRADE R35 GT-R | $600.00 | |
| SETUP KIT | |||
| 14020-AN006 | GT800 to GT1000 UPGRADE KIT | $7,000.00 | |
| 14020-AN007 | SET UP KIT GT900 R35 | $4,800.00 | |
| 14020-AN008 | SET UP KIT GT1000+ R35 | $5,500.00 | |
| 14020-AN009 | GTIII 800 UPGRADE KIT | $5,800.00 | |
| ACTUATOR UPGRADE KIT | |||
| 14030-AN001 | ACTUATOR UPGRADE R35 GT-R | $500.00 | |
| SYMMETRY TURBO OPTION PARTS | |||
| 14999-AK038 | FLANGE SET GTII7460 SYM | $120.00 | |
| 14999-AK039 | FLANGE SET GTII7867 SYM | $280.00 | |
| 14999-AK040 | GASKET SET GTII-SYM TURBO FLANGE | $32.00 | |
| 14999-AK041 | GASKET SET GTII7460SYM FRONT PIPE | $32.00 | |
| 14999-AK042 | GASKET SET GTII7867SYM FRONT PIPE | $32.00 | |
| 14999-AK043 | GASKET SET GTII7867SYM COMP OUTLET | $20.00 | |
| FORGED PISTON KIT | |||
| 21003-AN009 | PISTON KIT VR38 D95.5 | $1,680.00 | |
| 21004-AN017 | PISTON + CONROD KIT VR38 D95.5 S2 | $3,980.00 | |
| CAPACITY UPGRADE | |||
| 21003-AN011 | PISTON KIT VR38 4.3L | $4,000.00 | |
| 21004-AN019 | PISTON FULL KIT VR38 4.3L | $16,000.00 | |
| 23004-AN006 | CONROD SET VR38 4.1L STEP3 | $2,480.00 | |
| 23006-AN007 | CRANK SHAFT VR38 4.3L | $12,000.00 | |
| PISTON PIN AND RING | |||
| 21005-AN015 | PISTON RING SET N15 | $400.00 | |
| CAMSHAFT | |||
| 22002-AN038 | VCAM + VALVE SPRING KIT VR38 S2 | $2,500.00 | |
| METAL HEAD GASKET | |||
| 23009-AN010 | SMG/K KIT VR38DETT T=0.8 | $350.00 | |
| OIL FILLER CAP | |||
| 24003-AN001 | OIL FILLER CAP NISSAN/HONDA (RED) | $85.00 | BILLET OIL FILLER CAP |
| OTHER POWER TRAIN | |||
| 27001-AN001 | T/M OIL PAN UPGRADE FOR GR6(R35GT-R) | $900.00 | |
| 27006-AN002 | O/H BASIC SET R35 T/M | $500.00 | The retaining ring, fixture nut on the shaft's tip, etc. are included. Replace these parts every time after disassembly. Do not reuse these parts. |
| 27006-AN003 | FORK CONTACT PIECE R35 T/M | $1,300.00 | Parts on the shift fork's tip that touch the synchro-sleeve are included. Replace when abrasion is noticed. |
| 27006-AN004 | GEAR 6TH PAIR R35 T/M | $3,300.00 | 6th gear's parts. Replace if necessary after inspection when abnormal noise is noticed during the use of the 6th gear. |
| 27006-AN005 | GEAR 5TH PAIR R35 T/M | $3,300.00 | 5th gear's parts. Replace if necessary after inspection when abnormal noise is noticed during the use of the 5th gear. |
| 27006-AN006 | 2ND-4TH SET R35 T/M | $6,200.00 | 2nd & 4th gears' parts. Replace if necessary after inspection when abnormal noise is noticed during the use of the 2nd & 4th gear. |
| 27006-AN007 | GEAR 3RD PAIR R35 T/M | $3,300.00 | 3rd gear's parts. Replace if necessary after inspection when abnormal noise is noticed during the use of the 3rd gear. |
| 27006-AN008 | 1ST SET R35 T/M | $3,300.00 | 1st gear's parts. Replace if necessary after inspection when abnormal noise is noticed during the use of the 1st gear. |
| 27006-AN009 | BEARING SET R35 T/M | $2,700.00 | Bearing kit to use with the transmission. It is recommended to replace every time after disassembly. |
| 27006-AN010 | O/H BASIC SET R35 CLUTCH | $780.00 | The oil seal, retaining rig, bolts (hydraulically-actuated parts), etc. are included. Replace theses parts every time after disassembly. Do not reuse these parts. |
| 27006-AN011 | DISK SET R35 CLUTCH | $330.00 | 1 set includes 4 clutch disks. 4 sets are required to replace one clutch. Replace when abrasion and/or deformation is noticed. |
| 27006-AN012 | PLATE T0.7 SET R35 CLUTCH | $490.00 | Plates to adjust the clutch piston stroke to meet the standard stroke. 1 set includes 4 plates. |
| 27006-AN013 | PLATE T1.0 SET R35 CLUTCH | $490.00 | Plates to adjust the clutch piston stroke to meet the standard stroke. 1 set includes 4 plates. |
| 27006-AN014 | PLATE T1.3 SET R35 CLUTCH | $490.00 | 4 of 1.3mm thickness plates are included. A 1.3mm thick plate is the base plate for the clutch. 18 plates are required to replace one clutch. If 13mm is chosen for all plates, 5 sets are required. Replace when any error is detected or clutch engagement shows malfunction. |
| 27006-AN015 | PLATE T1.6 SET R35 CLUTCH | $490.00 | Plates to adjust the clutch piston stroke to meet the standard stroke. 1 set includes 4 plates. |
| 27006-AN017 | BEARING SET R35 CLUTCH | $90.00 | Bearing kit to use with the transmission. It is recommended to replace every time after disassembly. |
| OTHER COOLING KITS | |||
| 27002-AN002 | DCT FLUID COOLER R35 GT-R | $2,500.00 | |
| 27002-AN003 | DIFFERENTIAL OIL COOLER R35 GT-R | $2,500.00 | |
| 27002-AN004 | DCT FLUID COOLER R35 GT-R MY11 | $2,500.00 | |
| 27002-AN005 | DCT FLUID COOLER R35 GT-R MY17 | $2,800.00 | |
| RACING MUFFLER | |||
| 31008-KN001 | RACING MUFFLER R35 GT-R VR38DETT | $3,360.00 | Ground Clearance is stock -15mm |
| 31008-KN002 | RACING MUFFLER R35 GT-R W/SILENCER | $3,470.00 | Ground Clearance is stock -15mm, BOX#1 1630x675x305 (17.5kg) BOX#2 1855x520x330 (20.0kg) |
| LEGAMAX Premium | |||
| 31021-AN010 | LEGAMAX PREMIUM CBA-R35 VR38DETT | $3,050.00 | Modification of stock AL air guide is required for one made after 2010/11. |
| 31021-KN001 | LEGAMAX PREMIUM R35 VR38DETT FLUX | $2,240.00 | Flux Welding Type, BOX#1 LWH: 1615 X 650 X 270 (20.6kg), BOX#2 LWH : 1515 X 442 X 285 (8.8kg) |
| SUPERIOR specR | |||
| 31025-AN005 | SUPERIOR SPECR R35 VR38DETT GT-R | $5,040.00 | Modification of stock AL air guide is required for one made after 2010/11. |
| 3SX EXHAUST | |||
| 31025-AN006 | R35 GT-R 3STAGE EXHAUST SYSTEM | $10,000.00 | |
| METAL CATALYZER | |||
| 33005-AN005 | MTL CAT CBA-R35 GT-R VR38DETT | $4,970.00 | |
| F CON HARNESS | |||
| 42002-AN010 | F-CON HARNESS NP5-21 | $650.00 | |
| SPEED LIMITER DEFENCER | |||
| 45002-AN008 | VAC TYPE GT-R (MY11) | $900.00 | |
| PREMIUM SUCTION | |||
| 70018-AN007 | PREMIUM SUCTION R35 GT-R (MY11) | $880.00 | |
| RACING SUCTION | |||
| 70020-AN107 | RS R35 GT-R VR38DETT (MY11) | $1,000.00 | This product does not include turbo inlet pipes. It means that need to use OEM turbo inlet pipes. |
| 70020-AN110 | RS FULL KIT R35 GT-R VR38DETT | $1,600.00 | This product includes turbo inlet pipe. It means that full piping kit up to the turbo. |
| SUPER SQV4 | |||
| 71008-AN027 | SUPER SQV4 NISSAN GT-R R35 VR38DETT | $1,200.00 | |
| 71008-AN029 | SUPER SQV4 GT-R R35 VR38DETT (REPLACE) | $518.00 | Replacement type for the factory air bypass valve. |
| MAX IV SP | |||
| 80250-AN001 | MAXIVSP R35 FULL KIT | $4,300.00 | |
| MAX IV SP DRAG | |||
| 80250-AN001D | MAXIVSP DRAG R35 FULL KIT | $3,800.00 | |
| SUPER AIR FILTER | |||
| 70017-AN105 | SUPER AIR FILTER NISSAN TYPE5 | $39.00 | |
| COMPLETE ENGINE | |||
| 23011-AN005 | COMPLETE ENGINE VR38DETT 4.3L STEP3 | $55,000.00 | |
| 23011-AN011 | COMPLETE ENGINE VR38 4.3L STEP PRO | $70,000.00 | Doesn’t include intake mamifold, exhaust manifold, fuel system and other auxiliaries. |
| 23011-AN016 | COMPLETE ENGINE VR38 4.3L STEP PRO+ | $78,000.00 | Doesn’t include intake manifold, exhaust manifold, fuel system and other auxiliaries. |
| HIPERMAX S | |||
| 80300-AN001 | HIPERMAX S R35 FULL KIT | $2,880.00 | |
| HIPERMAX R | |||
| 80310-AN001 | HIPERMAX R R35 FULL KIT | $3,280.00 | |
| Super Turbo Muffler | |||
| 31029-AN010 | SUPER TURBO MUFFLER R35 VR38DETT | $4,000.00 | Vehicles released after 2010/11 require modification of the stock aluminum air guide plate. Applicable only to JDM "Pure Edition" for 2017 models. |
